Development Boards

RV-STAR Development Board

RV-STAR is a RISC-V development board based on GD32VF103 MCU

  • Microcontroller:GD32VF103VBT6(32-bit RISC-V Processor)
  • Power supply:5V USB or 5~9V External DC power(Arduino Vin)
  • Dimensions:66mm X 53.4mm
  • Arduino-Compatible Interface
  • Provide on-board debugger and JTAG interface

Detailed Introduction

Purchase link

Hummingbird FPGA Development Board

Hummingbird FPGA Development Board which is to prototype the Nuclei evaluation SoC (included RISC-V Core) in the FPGA,with the following characteristics:

  • Xilinx FPGA Chip (XC7A75T-2FGG484I).
  • Two DDR Chips (MT41K128M16JT-125K DDR III).
  • Two Crystal Oscillators, Y1 is for 100MHz Clock, Y2 is for 32.768K RTC Clock.
  • FPGA_FLASH, independent SPI Flash chip for FPGA to store its Bitstream (MCS format).
  • The jumpers, which can be used to configure the voltage level of FPGA_GPIO, as 1.8V, 2.5V, or 3.3V.
  • The FPGA_JTAG interface, which is the on-board USB JTAG programmer for programming the Bitstream of the FPGA.
  • Separated DC 5V power supply and a power switch.
  • The FPGA_PROG button to force the FPGA to re-load the Bitstream from the external Flash.
  • The MCU_FLASH, independent Flash chip for RISC-V core (burned inside FPGA) to store its instruction programs or read-only data.
  • The MCU_JTAG socket, which is the on-board JTAG interface socket for RISC-V Core debugging.
  • The MCU_GPIO connector, for 32 GPIO pins of the SoC.
  • The FPGA_RESET button for PoR reset of the SoC.
  • The MCU_RESET button for System reset of the SoC.
  • The button 1 and button 2.A
  • The LEDs.
  • The Switches.
  • The LEDs and Switches exposed connectors.
  • Up to 126 connectors for other FPGA IOs which can be used by user freely.
  • The RGB LEDs.

Detailed Introduction

Documents

Purchase link

HummingBird Debugger

Hummingbird debugger is specially designed for the development and debugging of SoC prototypes and MCU chips for Nuclei's Processor IP, with the following characteristics:

  • One end is a type A USB interface for direct connection to a PC, and the other end is a 10PIN horn socket, which can be directly connected to the Hummingbird FPGA development board
  • Support standard four-wire JTAG, two-wire JTAG debugging protocol, and two-wire serial port

Detailed Introduction

Download Driver

Purchase link
